Futaba T10PX 4-10 kanaler Rattradio F-4G/SR/T-FHSS med 3xR404SBS

Art.nr: 05003217-3
10.749,-

Produktet er midlertidig utsolgt. Dersom du ønsker å motta en epost når vi får det inn på lager, kan du legge igjen epostadressen din i skjemaet under.

Futaba

Futaba T10PX 4-10 kanaler Rattradio F-4G/SR/T-FHSS med 3xR404SBS

T10PX radiotilbud som inkluderer to ekstra R404SBS mottakere - tilbudet gjelder så lenge lageret rekker!

Futabas high-end modell 7PX-serie for biler og båter, som er foretrukket av mange av verdens beste sjåfører. Ved å ta over det DNA-et ble en ny "T10PX" født.

Med den nye kommunikasjonen F-4G har manøvreringsfølelsen anerkjent av verdensmesteren blitt bedre! Videre kan telemetrikommunikasjon, som ikke var mulig med T-FHSS SR-kommunikasjon, nå brukes. Med den nye funksjonen "Feeling" føles det som om den passer hver sjåfør! Støtter opptil 10 kanaler som fanger hjertene til skalaentusiaster. Vennligst nyt Futabas høyeste kvalitet modell på banen.

  • Den letteste i klassen og høybalansert design
  • Høyhastighetsrespons F-4G nytt system installert
  • "Følelse" - Ny funksjon for responsjustering
  • Støtter opptil 10 kanaler
  • Bred visningsvinkel fullfarge LCD tatt i bruk
  • Menyikon adoptert
  • Kan brukes som en spillkontroller ved å ta i bruk en ekstern USB-utgangsterminal
  • Ny hjulenhet / APA / APA angler / trigger tatt i bruk
  • Utskiftingsmekanisme for gasspjeld og styrefjær er tatt i bruk
  • Ny form multi-posisjon grep gummi
  • Girspakbryter + bunnbryter + 3-posisjonsbryter tatt i bruk
  • Støtter venstrehendte spesifikasjoner

*Når du slår på 10PX, kan lyse prikker vises på skjermen. Skjermen din inneholder et ekstremt stort antall TFT og er produsert ved hjelp av høypresisjonsteknologi. Eventuelle lyse prikker som kan vises på skjermen din er iboende av TFT-produksjonsteknologien.

Specifications - T10PX Transmitter:
Wheel system, 10 channels (F-4G System), 7 channels (SFHSS System), 4 channels (TFHSS-SR, T-FHSS systems)

  • Transmitting frequencies 2.4GHz band
  • Transmitting RF power output: 100 mW EIRP
  • Futaba F-4G/T-FHSS SR/T-FHSS/MINI-Z T-FHSS/S-FHSS
  • Transmitting antenna 1/2λdipole
  • 4.3 inch backlighted color TFT liquid crystal touch panel.

Included*:

  • T10PX Transmitter
  • R404SBS Receiver
  • Dry battery holder (Installed in transmitter)
  • Wheel offset adapter two size (APA)
  • APA Mounting screws (Spare screws are also included)
  • Wheel adapter 32 deg
  • Wheel Angle spacer 5 deg
  • Large diameter steering wheel
  • Trigger guard (Lx1 / Rx1)
  • Grip rubber x1
  • Blind paddle x2
  • Hex wrench
  • Short printed manual (Full manual only as PDF - click on the download tab to download)

*The contents of the set can change

Specifications R404SBS Receiver (Included):

  • Receiving frequency: 2.4GHz band
  • Telemetry Receiver RF power output: 1.02 mW EIRP
  • Power requirement: 3.7 V~7.4 V battery (Dry cell battery cannot be used.)
  • System: F-4G system/S.BUS2 system
  • Size: 25.5x20.7x10.6mm
  • Weight: 5.7g
  • Usable sensor options (As of October 2021):
    • Temperature sensor (SBS-01T) Perfect for engine head, etc.
    • Temperature sensor (SBS-01TE) Used by attaching to a motor, etc.
    • RPM Sensor (SBS-01RM) Measures speed over the 360 to 100,000rpm range.
    • Brushless type RPM Sensor (SBS-01RB) Measures speed over the 360 to 300,000rpm range.
    • Voltage Sensor (SBS-01V) Measures external power supply voltages up to 100V.
    • Current sensor (SBS-01C) Measures external power supply voltages up to 70V, capacity and consumption capacity
    • GPS sensor (SBS-01/02G) Detect the GPS and measure the position and speed of the car body.
    • Compatibility with non-Futaba sensors (Castle TL0). (Refer to the sensor instruction manual for more information.)

    System Type:
    • F-4G
    • T-FHSS
    • T-FHSS SR
    • T-FHSS (Mini-Z)
    • S-FHSS

    Hardware:
    • LCD: 4.3" TFT-LCD WQVGA (wide viewing angle)
    • LED: Blue
    • Sound: Speaker / Earphone Jack
    • Vibrator: Yes
    • Switch: 7x Push switch, 1x Push lock switch & 1x Slide switch
    • Trim: 6x Digital trim & 1x Dial trim
    • Edit Key: Touch panel & 4x Push switch
    • Display Switch: Yes
    • Wireless charger (option): Yes

    Battery (optional):
    • Li-Fe 2cells 6.4V 1700mAh
    • Ni-MH 5cells 6.0V 1800mAh
    • LiPo 2cells 7.4V 2000mAh

    Software:
    • D/R & ATL: Steering, Throttle (forward) & Throttle (brake)
    • Steering Speed: Turn & Return
    • Throttle Speed: Turn, Return & Point (2 points)
    • Steering Curve: EXP, VTR & CRV (21 points)
    • Throttle Curve: EXP, VTR & CRV (21 points)
    • Brake Curve: EXP, VTR & CRV (21 points)
    • Fail-Safe (all channels): OFF, Fail-safe, Hold, Battery fail-safe (variable voltage)
    • EPA: EPA (all channels) & EPA trim
    • Sub Trim: All channels
    • Channel Reverse: All channels
    • Trim: All channels
    • Throttle Mode: 50:50, 60:40, 70:30 & 100:0
    • ABS: Return, Delay, Cycle speed, Duty ratio, Trigger point & Trigger point reverse
    • Traction Control: Yes
    • Idle Up: Yes
    • Neutral Brake: Yes
    • Acceleration: Yes
    • Start: Yes
    • Engine Cut: Yes
    • AUX Channel: CH3-10
    • 4WS Mixing: Front/Reverse/Normal/Rear
    • Dual ESC: Yes
    • Brake Mixing: Yes
    • Steering Mixing: Yes
    • Tilt Mixing: Yes
    • Gyro Mixing: Yes
    • CPS Mixing: 3
    • Programmable mixing: 5, EXP, VTR, CRV (21 points)
    • Telemetry Mixing: Yes
    • Tank Mixing: Yes
    • Channel Limiter: All channels
    • Timer: Up timer, Down timer, Lap timer, Lap navigate timer & Lap list (80 laps)

    Telemetry:
    • Temp. sensor
    • RPM sensor
    • Voltage sensor
    • Current sensor
    • GPS
    • ESC (Castle TL01, MC970CR)
    • Voice alarm
    • Recording log
    • Telemetry Mixing (Programmable mixing)

    Other:
    • Model Select: Yes
    • Model Name: Yes
    • Model Copy: Yes
    • Data Reset: Yes
    • Condition: 4 different & Condition copy
    • User Menu: Yes
    • Servo View: Yes
    • Display setting: Brightness
    • LED setting: Mode (Off / always on / backlight) & Brightness
    • Adjuster: Yes
    • User Name: 15 characters
    • Auto Power Off: Yes
    • Updates: Yes
    • Receiver Updates: R404SBS & R334SBS
    • Roll out chart: Yes
    • Gear ratio chart: Yes
    • Servo setting: Wired & Wireless
    • MC Link: Wired & Wireless

    System menu
    • Display settings
    • System information
    • Voice
    • Battery settings
    • Date and time
    • LED settings
    • Adjuster
    • Receiver update
    • Servo update

    Model menu
    • Model select
    • Model copy
    • Model name
    • Model deletion (in SD card)
    • Data reset
    • Model type *New function

    Setup menu
    • Receiver settings
    • Servo view
    • Throttle mode
    • Reverse
    • Sub trim
    • Endpoint
    • Fail-safe function
    • Acceleration
    • Trim / dial settings
    • Switch settings
    • Condition
    • Idle-up
    • D/R, ATL
    • Channel limiter
    • Channel settings

    Racing menu
    • Curve (EXP) 111
    • Speed
    • Traction control
    • A.B.S.
    • Start
    • Engine cut
    • Feeling *New function

    Mixing menu
    • Steering mixing
    • Brake mixing
    • Gyro mixing
    • 4WS mixing
    • Dual ESC
    • CPS mixing (1.2.3)
    • Tank mixing
    • Program mixing (1.2.3.4.5)
    • Tilt mixing

    Telemetry menu
    • Telemetry system
    • Telemetry
    • Sensor list
    • Sensor menu

    Accessory menu
    • Timer
    • Wrap list
    • S.BUS servo
    • MC (ESC) link
    • Gyrolink
    • Index table
    • Gear ratio table
    • Home / ES1 / ES2 / ES3 button settings
    • Home screen display settings



http://www.futabarc.com
